Cable Carabiner Sling Anchor with Vinyl Coated Galvanized Steel Cable—
$87.00
The Story
Cable Carabiner Sling Anchor with Vinyl Coated Galvanized Steel Cable
FEATURES
- Hard-wearing 1/4" vinyl coated galvanized steel cable tolerates demanding work environments
- Non-choking, trouble-free wrap-around and connect installation.
- Captivated carabiner and one connecting ring secure anchor to overhead structures
- Secondary connecting ring facilitates connection of SRL or lanyard
- Features plated alloy steel connecting rings and carabiner
- Assembled with steel thimbles and swaged aluminum ferrules
- Vinyl coating adds a layer of protection and provides easier clean-up
- Complies with ANSI Z359.18-2017
MATERIAL SPECIFICATIONS
Cable: 1/4" vinyl coated galvanized steel; 5,000 lb min. static strength
D-rings: Plated alloy steel; 5,000 lb min. static strength
Carabiner: Plated alloy steel; 5,000 lb min. static strength with 3,600 lb gate strength
PERFORMANCE SPECIFICATIONS
Static Strength: 5,000 lb min.
ANSI User Capacity: 130 to 310 lb max.
OSHA User Capacity: 130 to 425 lb max.
SIZES & PART NUMBERS
- 84202DC3 - 3'
- 84202DC4 - 4'
- 84202DC - 6'
- 84202DC8 - 8'
DOWNLOADS
Instruction Manual
Declaration of Conformity
COMPLIANT WITH:
ANSI Z359.18-2017
OSHA 1926.205 and 1910.66
