Doughty Side Entry Clamps

Doughty Side Entry Clamps



These Side Entry Doughty Clamps are ideally used in a place where height is at a premium and a clamp that fully encompasses the tube is required. This Clamp is suitable for cross bracing and suspensions where a firm fixing is required and a claw clamp is not appropriate.

A high tensile extruded aluminium clamp that is suitable for 48mm to 51mm (1.89″ – 2.01″) diameter tubes. It has a WLL of 750Kg and is 50mm (1.97″) wide. Slotted to hold captive an M12 nut or bolt head, it is ideal for where height is at a premium and a clamp that fully encompasses the tube is required. Suitable for cross bracing and suspensions where a firm fixing is required and a claw clamp is not appropriate. Available in polished silver or powder coated black.

Downloads:

User Manual

---

Key Features:

• High tensile extruded aluminium construction
• Compatible with 48mm to 51mm (1.89″ – 2.01″) diameter tubes
• Slotted to hold captive an M12 nut or bolt head
• Ideal for applications where height is restricted
• Available in polished silver or powder coated black

---

Specifications:

• WLL: 750kg
• Tube Diameter: 48mm – 51mm (1.89” – 2.01”)
• Clamp Width: 50mm (1.97")

---

References:

• High tensile aluminium for durability and strength
• Cross bracing and suspension compatible
• Designed where a claw clamp is not appropriate
